3 Pin M12 Female Panel Mount Connector A Code For Automation Applications

Product Categories
Dongguan Cableforce Electronics Co., Ltd
Contact Now

3 Pin M12 Female Panel Mount Connector A Code For Automation Applications

Brand Name : CABLEFORCE

Model Number : MC04P4XLSDP9-22W02

Certification : CUL Certified, CE/ EMC, IP67

Place of Origin : Guangdong, China

MOQ : 100

Price : Negotiated

Payment Terms : T/T

Supply Ability : 60000 pcs/month

Delivery Time : 2~3 weeks

Packaging Details : Our standard packing: Individual part with transparent PE bag with label, OEM packing available.

Contacts Poles : 03 Pin

Cable Length : 0.5M

Connector Gender : Female connector

Cable Jacket : PVC

Keyway Coding : A-Coding

Tightening Torque : 0.6Nm

Cable Color : Brown, Blue, Black

Wire gauge : AWG 22

Contact Now

Automation M12 Circular Connector Female Rear Mount Panel Position Adjustable
Connector Technical Data
Model Number
 MC04P4XLSDP9-22W02
Connectors No.
4 Pin
Rated Current
4A
Rated Voltage
250V
Impulse Voltage
2500V
O ring FKM, Silicon
Insulation resistance 100MΩ
Contact resistence 5MΩ
Termination Soldering
Screw nut Brass, CNC, Nickel plated
Pollution degree
 3
Description
M12 connectors are circular connectors with a 12-mm locking thread used for sensors, actuators, Fieldbus and industrial Ethernet, primarily in factory automation applications. Often with ratings ofIP65, IP68 and IP69K, they are ideal for washdown and corrosive environments. The M12 family can be found in many applications such as factory automation, measurement and control, communications, food and beverage, transportation, agriculture, robotics and alternative energy.

CABLEFORCE Products Features

● Mouting type: rear mount, front mount.
● 2P, 2+3P, 3P, 4P, 5P, 8P, 12P and 17 poles are available
●Current rating: 16A, 12A, 8A, 4A, 2A, 1.5A

●SUS 316 Stainless steel screw is available

●Degree of protection IP 67

●Operating voltage: 690V, 630V, 600V, 300V DC, 250V AC, 72V DC, 60V AC, 48V, 30V

FAQ

● What is the code?

A-, B-, D- and X-coded are most prevalent. This is because the A-, B- and D-coded connectors have been around for a long time and are some of the original M12 connectors. X-coded connectors are becoming more popular for high-speed industrial Ethernet and will eventually replace the A and D-coded parts for Ethernet applications.3 Pin M12 Female Panel Mount Connector A Code For Automation Applications


Product Tags:

3 Pin M12 Female Panel Mount Connector



M12 Female Panel Mount Connector



M12 A Coded Female Connector


Quality 3 Pin M12 Female Panel Mount Connector A Code For Automation Applications for sale

3 Pin M12 Female Panel Mount Connector A Code For Automation Applications Images
